Ceratizit
7.855301003E9
MAXILOCK S TOOLHOLDER
Specifications
| Overall Length (Metric) | 101.6 |
|---|---|
| Series | MaxiLock-S |
| Toolholder Style | SCLCL |
| Overall Length (Inch) | 4.0 |
| Short Description | SCLCL 10-3 |
| Long Description | MAXILOCK S TOOLHOLDER SCLCL 10-3 |
| Direction Of Hand | Left |
| Unit Of Measure | Imperial |
| Material | Steel |
| Shank Width | 0.63 Inch |
| Shank Width (Metric) | 15.88 |
| Shank Height (Metric) | 15.88 |
| Functional Width (Decimal) | 0.75 |
| Functional Width (Metric) | 19.05 |
| Head Length (Decimal) | 0.63 |
| Head Length (Metric) | 16.01 |
| Connection Type | VKT - Square |
| Reduced Body Diameter Length (Metric) | 16.01 |
| Reduced Body Diameter Length (Decimal) | 0.63 |
| Holder Form | SCLC95 |
