Ceratizit
7.11542E7
PCBN TURNING INSERT
Specifications
| Thickness (Metric) | 1.58 |
|---|---|
| Corner Radius (Metric) | 0.2 |
| Material | PCBN |
| Included Angle | 80 degrees |
| Corner Radius (Inch) | 0.01 |
| Style | WCGW |
| Thickness (Inch) | 0.07 |
| Short Description | WCGW 020102FN_F3 CTBS10U |
| Long Description | PCBN TURNING INSERT WCGW 020102FN_F3 CTBS10U |
| Grade | CTBS10U |
| Unit Of Measure | Metric |
| Cutting Edge Length | 2.70 mm |
| Inscribed Circle Diameter | 3.97 mm |
| Inscribed Circle Diameter (Decimal) | 0.16 |
| Cutting Edge Length (Decimal) | 0.11 |
| Direction Of Hand | Neutral |
| Clearance Angle Major | 7 degrees |
| Screw Hole Diameter (Decimal) | 0.1 |
| Screw Hole Diameter (Metric) | 2.3 |
| Cutting Edge Effective Length (Metric) | 2.7 |
| Cutting Edge Effective Length (Decimal) | 0.11 |
| Tolerance Class | G |
