Ceratizit
7.0778016E9
MAXILOCK S EXTERNAL TOOLHOLDER
Specifications
| Overall Length (Metric) | 100.0 |
|---|---|
| Series | MaxiLock-S |
| Toolholder Style | STGCR |
| Overall Length (Inch) | 3.94 |
| Short Description | STGCR 1616 H16 DC |
| Long Description | MAXILOCK S EXTERNAL TOOLHOLDER STGCR 1616 H16 DC |
| Direction Of Hand | Right |
| Unit Of Measure | Imperial |
| Material | Steel |
| Shank Width | 0.63 Inch |
| Shank Width (Metric) | 16.0 |
| Shank Height (Metric) | 16.0 |
| Functional Width (Decimal) | 0.79 |
| Functional Width (Metric) | 20.0 |
| Head Length (Decimal) | 1.19 |
| Head Length (Metric) | 30.0 |
| End Chamfer Angle | 45 degrees |
| End Chamfer Distance (Decimal) | 0.16 |
| End Chamfer Distance (Metric) | 4.0 |
| Connection Type | VKT - Square |
| Coolant Entry Thread Size | G1/8 |
| Coolant Radial Entry Thread Size | M6 |
| Functional Height (Metric) | 19.0 |
| Functional Height (Decimal) | 0.75 |
| Overall Height (Metric) | 24.7 |
| Overall Height (Decimal) | 0.98 |
| Tightening Torque (Nm) | 3,2 |
| Holder Form | STGC90 |
