Ceratizit
7.0778012E9
MAXILOCK S EXTERNAL TOOLHOLDER
Specifications
| Overall Length (Metric) | 80.0 |
|---|---|
| Series | MaxiLock-S |
| Toolholder Style | STGCR |
| Overall Length (Inch) | 3.15 |
| Short Description | STGCR 1212 F11 DC |
| Long Description | MAXILOCK S EXTERNAL TOOLHOLDER STGCR 1212 F11 DC |
| Direction Of Hand | Right |
| Unit Of Measure | Imperial |
| Material | Steel |
| Shank Width | 0.48 Inch |
| Shank Width (Metric) | 12.0 |
| Shank Height (Metric) | 12.0 |
| Functional Width (Decimal) | 0.63 |
| Functional Width (Metric) | 16.0 |
| Head Length (Decimal) | 0.68 |
| Head Length (Metric) | 17.1 |
| End Chamfer Angle | 45 degrees |
| End Chamfer Distance (Decimal) | 0.16 |
| End Chamfer Distance (Metric) | 4.0 |
| Connection Type | VKT - Square |
| Coolant Entry Thread Size | M6 |
| Coolant Radial Entry Thread Size | M6 |
| Functional Height (Metric) | 12.0 |
| Functional Height (Decimal) | 0.48 |
| Overall Height (Metric) | 16.1 |
| Overall Height (Decimal) | 0.64 |
| Tightening Torque (Nm) | 1,2 |
| Holder Form | STGC90 |
