Ceratizit
7.0775116E9
MAXILOCK S EXTERNAL TOOLHOLDER
Specifications
| Overall Length (Metric) | 100.0 |
|---|---|
| Series | MaxiLock-S |
| Toolholder Style | SRDCN |
| Overall Length (Inch) | 3.94 |
| Short Description | SRDCN 1616 H08 DC |
| Long Description | MAXILOCK S EXTERNAL TOOLHOLDER SRDCN 1616 H08 DC |
| Direction Of Hand | Neutral |
| Unit Of Measure | Imperial |
| Material | Steel |
| Shank Width | 0.63 Inch |
| Shank Width (Metric) | 16.0 |
| Shank Height (Metric) | 16.0 |
| Functional Width (Decimal) | 0.48 |
| Functional Width (Metric) | 12.0 |
| Head Length (Decimal) | 1.19 |
| Head Length (Metric) | 30.0 |
| Connection Type | VKT - Square |
| Coolant Entry Thread Size | G1/8 |
| Coolant Radial Entry Thread Size | M6 |
| Functional Height (Metric) | 16.0 |
| Functional Height (Decimal) | 0.63 |
| Overall Height (Metric) | 21.7 |
| Overall Height (Decimal) | 0.86 |
| Tightening Torque (Nm) | 1,8 |
| Holder Form | SRDC0 |
