Ceratizit
7.077003201E9
MAXILOCK S EXTERNAL TOOLHOLDER
Specifications
| Overall Length (Metric) | 170.0 |
|---|---|
| Series | MaxiLock-S |
| Toolholder Style | SCLCL |
| Overall Length (Inch) | 6.7 |
| Short Description | SCLCL 3225 P12 DC |
| Long Description | MAXILOCK S EXTERNAL TOOLHOLDER SCLCL 3225 P12 DC |
| Direction Of Hand | Left |
| Unit Of Measure | Imperial |
| Material | Steel |
| Shank Width | 0.99 Inch |
| Shank Width (Metric) | 25.0 |
| Shank Height (Metric) | 32.0 |
| Functional Width (Decimal) | 1.26 |
| Functional Width (Metric) | 32.0 |
| Head Length (Decimal) | 1.03 |
| Head Length (Metric) | 26.0 |
| End Chamfer Angle | 45 degrees |
| End Chamfer Distance (Decimal) | 0.56 |
| End Chamfer Distance (Metric) | 14.0 |
| Connection Type | VKT - Square |
| Coolant Entry Thread Size | G1/8 |
| Coolant Radial Entry Thread Size | G1/8 in |
| Functional Height (Metric) | 32.0 |
| Functional Height (Decimal) | 1.26 |
| Overall Height (Metric) | 37.7 |
| Overall Height (Decimal) | 1.49 |
| Tightening Torque (Nm) | 5.0 |
| Holder Form | SCLC95 |
