Ceratizit
7.076701401E9
MAXILOCK S EXTERNAL TOOLHOLDER
Specifications
| Overall Length (Metric) | 150.0 |
|---|---|
| Series | MaxiLock-S |
| Toolholder Style | SCDCL |
| Overall Length (Inch) | 5.91 |
| Short Description | SCDCL 1414 M09 DC |
| Long Description | MAXILOCK S EXTERNAL TOOLHOLDER SCDCL 1414 M09 DC |
| Direction Of Hand | Left |
| Unit Of Measure | Imperial |
| Material | Steel |
| Shank Width | 0.56 Inch |
| Shank Width (Metric) | 14.0 |
| Shank Height (Metric) | 14.0 |
| Functional Width (Decimal) | 0.56 |
| Functional Width (Metric) | 14.0 |
| Head Length (Decimal) | 0.99 |
| Head Length (Metric) | 25.0 |
| Connection Type | VKT - Square |
| Coolant Entry Thread Size | G1/8 |
| Coolant Radial Entry Thread Size | M6 |
| Functional Height (Metric) | 14.0 |
| Functional Height (Decimal) | 0.56 |
| Overall Height (Metric) | 17.2 |
| Overall Height (Decimal) | 0.68 |
| Tightening Torque (Nm) | 3,2 |
| Holder Form | SCDC45 |
