Ceratizit
7.028745E7
CARBIDE TURNING INSERT
Specifications
| Thickness (Metric) | 1.59 |
|---|---|
| Corner Radius (Metric) | 0.2 |
| Material | Carbide |
| Included Angle | 80 degrees |
| Corner Radius (Inch) | 0.01 |
| Style | WCGT |
| Thickness (Inch) | 0.07 |
| Short Description | WCGT 020102EN-SF CTPP430 |
| Long Description | CARBIDE TURNING INSERT WCGT 020102EN-SF CTPP430 |
| Grade | CTPP430 |
| Unit Of Measure | Metric |
| Cutting Edge Length | 2.710 mm |
| Inscribed Circle Diameter | 3.97 mm |
| Inscribed Circle Diameter (Decimal) | 0.16 |
| Cutting Edge Length (Decimal) | 0.11 |
| Direction Of Hand | Neutral |
| Clearance Angle Major | 7 degrees |
| Chip Breaker | -SF |
| Screw Hole Diameter (Decimal) | 0.09 |
| Screw Hole Diameter (Metric) | 2.1 |
| Rake Angle | 15 degrees |
| Tolerance Class | G |
